ProfiCAD is a fast, efficient, and user-friendly CAD software designed primarily for creating electrical and electronic diagrams, schematics, and control circuit diagrams. In addition to electrical engineering, it can also be used to design other technical schematics, such as pneumatics, hydraulics, and floor plans
Key Features
- Extensive Symbol Library: It comes with a massive pre-installed library of standard electrical symbols. Users can also easily create custom symbols or customize existing ones.
- Automatic Formatting: The software generates a comprehensive netlist, wire list, and bill of materials (BOM) automatically, saving engineers hours of manual sorting.
- Multi-page Documentation: It supports complex, multi-page drawings where cross-references are automatically updated across different sheets.
- AutoCAD Compatibility: ProfiCAD allows users to import and export drawings in DXF and DWG formats, making collaboration with AutoCAD users seamless.
- Unicode Support: The software supports full Unicode text, allowing users to type and insert text in any language.
