Are you looking for tools like Multisim, SPICE, LTspice, Proteus, Altium or PhET simulations? That's great! PROTO is an real time electronic circuit simulator which means you are able to setup a circuit with various components and simulate behaviour of the electronic circuit
During simulation you can check voltages, currents and many other variables. Check signals on multichannel oscilioscope and tune your circuit in real time! Our app can greatly help with your Raspberry Pi, Arduino or ESP32 project. You can also use PROTO as logic circuit simulator and perform digital electronic analysis!
Features:
- Animations of voltage values and current flows
- Adjusts circuit parameters (like voltage, current and other)
- Four-channel oscilloscope
- Single play/pause button to control simulation
- Copy electronic components
- Learn about electronic circuits by examples in app
- Share circuit with friends
- Themes (Dark, Light, Ocean, Solarized)
- PNG, JPG, PDF circuit export
- Export workspace
- Video tutorials about electronics
- Arduino support in future
